HDMI & HDBaseT Extenders
PS-HDEW3
HDMI & USB-C HDBaseT Wall Plate Transmitter
The PS-HDEW3 is a professional HDBaseT wall plate transmitter designed for modern conference rooms, classrooms, boardrooms and collaborative AV environments. Featuring 2 HDMI inputs and 1 USB-C input, it provides seamless source switching and long-distance transmission over a single CAT5e/CAT6 cable.
Key Features
- 2 HDMI Inputs + 1 USB-C Input
- HDBaseT Extension up to 100m
- 4K UHD Video Support
- Auto / Manual Source Switching
- POC (Power over Cable)
- EDID Management
- Bi-Directional IR Extension
- RS-232 Device Control
- Programmable Wall Plate Buttons
- Single CAT5e/CAT6 Transmission
Technical Specifications
| Model | PS-HDEW3 |
|---|---|
| Inputs | 2 × HDMI, 1 × USB-C |
| Output | 1 × HDBaseT |
| Video Resolution | Up to 4K UHD |
| Transmission Distance | Up to 100m |
| POC | Supported |
| IR Extension | Bi-Directional |
| RS-232 | Supported |
| Installation Type | Wall Plate |
| Power Supply | POC / External Power |
Refer to the datasheet for complete operating conditions and model selection.
Support & Downloads
PS-HDEW3 Datasheet
Download PDF ↓HDMI & USB-C HDBaseT Wall Plate Transmitter
